RME Setup & Application Schematics

RME Audio solutions provide unmatched flexibility for modern production, recording, and live environments. From seamless conversion between AVB/MILAN and Dante networks to powerful multitrack recording with up to five 12Mic units via MADI, RME covers every workflow. Expand your interface easily through ADAT or MADI, and shape your sound with precision using Room Correction and EQ inside TotalMix FX, ideal for Dolby Atmos calibration or fine-tuning an analog studio setup.

For mastering, the ADI-2/4 Pro and Babyface Pro with ADI-2 deliver pristine processing, while the Fireface UFX II versatility shines in DJ and live performance scenarios. The Fireface UFX III enables powerful live setups and system integration, complemented by network-ready solutions like the Digiface Dante for advanced studio applications.

With RME’s schematics and application guides, you can configure tailored workflows—from recording and mastering to live sound and immersive audio—with maximum reliability and sonic integrity.

• Converting AVB/MILAN to DANTE and vice versa
• Recording with 5x 12Mic via MADI and DURec backup recording
• Expand your Interface with digital ADAT or MADI
• Calibrate a Dolby Atmos Setup with the RME Room Correction in TotalMix FX
• Analog Studio with Room EQ
• ADI-2/4 Pro for Final Mastering Processing
• Babyface Pro & ADI-2 for Final Mastering Processing
• Fireface UFX II DJ / Live Performance
• Fireface UFX III Live Setup
• Digiface Dante Studio Application Example
• Fireface UFX III System Integration Example
